SILVANET BORDER GATEWAY

Early detection wildfire alerts are made possible thanks to Dryad's Border Gateway. Get in touch to learn more about our distributed LoRaWAN® Gateway for Large-Scale Outdoor Networks

The Silvanet Border Gateway is placed at the border of the target forest area, typically in a forest house or near a village. The Border Gateway communicates with the Silvanet Cloud Platform, relaying messages from Wildfire Sensors (directly or indirectly via Mesh Gateways). Connectivity is provided wirelessly using the built-in LTE radio (using 4G/LTE-M with 2G/GPRS fallback) or using the built-in Ethernet adapter via a wired Internet connection. For remote deployments where there is no mobile network coverage and no access to mains power, the Silvanet Border Gateway has built-in support for satellite uplink using the SWARM satellite network. It can be operated on mains power or powered by a solar cell.



Silvanet Border Gateway, LoRaWAN, 4G, LTE-M, 2G, GPRS, 3GPP, Solar-powered, Ethernet, Supercapacitors, Distributed, Mesh Network, IoT Sensor, Wildfire, Forest Fire, Forestry, Outdoor

DIFFERENTIATORS

  • Solar- or mains powered

  • Built-in satellite communications (SWARM)

  • Extends to large areas with Mesh Gateway

FEATURES

  • Ethernet, 4G/LTE-M, 2G/GPRS fallback

  • LoRaWAN compliant

  • Firmware Update Over-the-Air

MESH NETWORK ARCHITECTURE

Silvanet, Mesh Network, LoRaWAN, Distributed, Infrastructure, Forestry, Solar-powered, Cloud Platform, AWS, Silvanet
Solution

TECHNICAL DATA

MECHANICAL SPECIFICATION

Size
63 x 46 x 4,5cm
Weight
1,3kg
Solar Panel
Optional, external, 67 x 36cm
Operational Temperature
-40℃ to +85℃
Operational Humidity
0% to 100% Condensing
Ingress Protection
IP64
Material
Plastic (Weather, UV-proof)

REGULATORY COMPLIANCE

Regulatory (US)
FCC Part 15.247, 109, 209
EMC
ETSI EN 300 019
ETSI EN 55024
ETSI EN 300 489

ULTRA-EARLY
FIRE DETECTION

HEALTH & GROWTH MONITORING

GENRAL CHARACTERISTICS

Maintenance
Maintenance-free (10-15 yr)
Mesh Gateway to Border Gateway (ratio)
Typically 20 Mesh Gateways per 1 Border Gateway
Power source
Mains powered (PoE) or Solar panel (optional), battery-free
Energy storage
Supercapacitors
Installation
Mounted on pole or attached to a tree

BUILT-IN CONNECTIVITY

Wired connection
Ethernet
Wireless connection
4G/LTE-M, 2G/GPRS fallback
Satellite
SWARM up- and downlink

EXTERNAL CONNECTIVITY

Starlink
Space X / Starlink service
Other satellite Internet
VSat iFast Ku or C-Band

LORA RADIO PARAMETERS

ISM Bands
NA902-928, AU915
ISM Bands
EU868, AS923
Tx Power
22 dBm
Receive Channels
4
Transmit Channels
1
Antenna connection
N-Type
Graphical diagram of Dryad's Silvanet Border Gateway
